32-Channel Digital Mixing Console - 翻译中... PDM-32

Channel Processing

Input Processing Channels

32 microphone or line inputs, 1 stereo USB playback, 1 talkback microphone input, 2 expandable digital inputs.

Output Processing Channels

16 –channel AUX, 1-channel MAIN, 1-channel stereo monitor, 1-channel stereo USB recording, 2-channel expandable digital outputs.

Internal Effects

4 mono channels with FX1 and FX2 featuring echo and reverb effects, and FX3 and FX4 featuring chorus, wow, tremolo, distortion, pitch shift, and flange effects.

GEQ Modules

6 × 31-band GEQ modules, including 2 GEQ modules for input channels; 4 GEQ modules for output channels

Noise Gate

Threshold: -100dB to -20dB, with noise gate and side chain ducking modes

Compressor

Threshold: -48dB to +12dB

Attack time: 3ms to 100ms

Release time: 2x, 4x, 6x, 8x, 16x, 32x (release time is a coefficient multiplied by the attack time)

Compression ratio: 1.0 to 127,

Soft knee: 0 to 20dB

Equalizer

Input: 5 bands, output: 9 bands

Frequency :20Hz to 20kHz (-20dB/+12dB)

Q value :0.404 to 28.852

Types :PEQ, High Shelving, Low Shelving.

High-Pass / Low-Pass Filters (HPF / LPF

Z)

High-pass: 20Hz to 400Hz (6/12/24/36/48dB slope)

low-pass: 120Hz to 20kHz (6/12/24/36/48dB slope)

Delay

0 to 500ms

Phase

Standard/Inverted

Scene Files

Up to 100 scenes can be saved

Effect Library Files

Up to 100 effect presets can be saved

Signal Processing Capability

40-bit floating-point processing, 48kHz sample rate

A/D Converter

32-bit, 192kHz, 115dB dynamic rang

D/A Converter

24-bit, 192kHz, 127dB dynamic range

Connectors

Microphone/Line

Input XLR Interface

32, including 8 combo jacks, balanced input

Talkback Input

XLR Interface

1

XLR Output Interface

16

Minitor Output XLR Interface

2 Stereo

Headphone Output TRS Interface

1 Stereo

Digital Input / Output Expansion Interface

Supports DANTE 2X2,Bluetooth, AES, USB stereo sound card and HMLINK expansion card

USB Interface

2, for connecting USB flash drives for stereo recording/playback, connecting WiFi module

for wireless control

Lamp XLR Interface

DC 12V output, switch and brightness can be configured

Serial Port

RS232 DB9 serial port, configurable baud rate

IN 1-24 Inputs

Input Impedance

Unbalanced 5kΩ, balanced 10kΩ

Frequency Response

20Hz to 20kHz (+/-0.5dB)

Maximum Input Level

22dBu

Phantom Power

+48V(IN1 to IN24)

Gain

-12dB to 40dB

S/N

115dB (gain = 0dB, A-weighted)

Dynamic Range

116dB (gain = 0dB, A-weighted)

Equivalent

Input Noise

-110dBu (gain = 40dB, output = +4dB)

OUT 1-12 Outputs

THD

0.004% (gain = 0dB, output = 0dBu, unweighted)

0.01% (gain = 40dB, output =0dBu, unweighted)

Frequency Response

20Hz to 20kHz (+/-0.5dB)

Maximum Output Level

+22dBu

Output Impedance

＜100Ω

Crosstalk

-113dB@1kHz

Noise Floor

-86dBu (gain = 0dB)

Monitor and Headphone

Output Impedance

＜50Ω

Maximum Output Level

+20dBu

Noise Floor

-81dB (potentiometer = MAX, volume = 0dB)

Talkback Microphone

Input Impedance

Unbalanced 3kΩ, balanced 6kΩ

Maximum Input Level

+6.5dBu (potentiometer = MAX, intercom volume = MAX)

Digital I/O

Digital I/O

Bluetooth, AES/EBU, DANTE 2X2, stereo sound card

USB stereo playback and recording, supports mp3, wav, and flac file playback.

USB Format

3.0

Recording Format

Wav

General

Maximum Gain

80dB from analog input to output

Channel Crosstalk

-110dB

Display Screen

10.1 "touch screen 1280x800 resolution

Linear Potentiometers

25 X 100mm electric linear potentiometers

System

Android

Network

External WiFi module, supports control from iOS, Android, and PC

Hardware

Power

AC 100-240V 50/60Hz

Power Dissipation

50W

Work Temperature

5℃~40℃

Dimensions (W×D×H)

Machine: 836x527.3x225.7mm

Package: 985x665x370mm

Weight

Net Weight: 18.8kg

Gross Weight: 26.4kg

Accessories

WiFi Module

Power Cable
