The DSP5210 series products include multiple models, each equipped with a different number of speaker units and tweeters to meet different audio needs and application scenarios.
High-quality aluminum alloy structure, stable and durable, suitable for various decoration places.
Featuring a 4.5" full-range speaker and 1" tweeter, this speaker offers focused sound energy and superior clarity.
The product's sensitivity ranges from 88dB to 90dB, the rated power ranges from 100W to 600W, and the maximum sound pressure level is up to 117.8dB, making it suitable for application environments that require high volume and clarity.
The coverage angle of the DSP5210 series speakers is designed to be 140°(H)×20°(V), which not only ensures sound clarity and uniformity, but also takes into account the optimization of the spatial sound field.
This speaker uses a unique combination of a 4.5" paper cone speaker and a 1" tweeter. The design focuses on high sensitivity and low distortion, bringing soft and pleasant sound quality and natural and simple tone. The aluminum alloy box structure has stronger airtightness. The high-quality aluminum alloy structure is stable and durable, and it is not easy to produce noise. The streamlined metal mesh design is closely integrated with the box, reflecting the beauty and generosity of the product. This speaker is suitable for small and medium-sized places such as restaurants, teahouses, stations, schools, squares, office buildings, small and medium-sized conference rooms, home theaters, churches, etc.
Model | DSP5210 | DSP5420 | DSP5630 | DSP5840 | DSP1260 | |
Speaker Unit | Full-range | 4.5"x2 | 4.5"x4 | 4.5"x6 | 4.5"x8 | 4.5"x12 |
Tweeter | 1"x1 | 1"x1 | 1"x1 | 1"x1 | 1"x1 | |
Rated Power (RMS) | 100W | 200W | 300W | 400W | 600W | |
Impedance | 8Ω | 8Ω | 8Ω | 8Ω | 8Ω | |
Freq. Response | 120-18KHz | 120-18KHz | 110-18KHz | 110-18KHz | 95-18KHz | |
Sensitivity | 88dB | 89dB | 90dB | 90dB | 90dB | |
Maximum SPL | 108dB | 112dB | 114.7dB | 116dB | 117.8dB | |
Coverage Angle | 140°(H)×20°(V) | 140°(H)×20°(V) | 140°(H)×20°(V) | 140°(H)×20°(V) | 140°(H)×20°(V) | |
Dimension(LxWxH) | 123*142*393mm | 123*142*653mm | 123*142*912mm | 123*142*1166mm | 123*142*1687mm | |
Net Weight | 3.84KG | 6.46KG | 9.02KG | 11.65KG | 16.63KG | |
