Model | DSP1580 |
Whole System | |
MAX. SPL. | 132dB |
Sensitivity | 98dB |
Line Array Speaker | |
Frequency Response | 75Hz-20KHz (±3dB) |
Sensitivity | 95dB/W (lm) |
MAX. SPL. | 120dB MAX. |
Nominal Impedance | 8Ω |
Nominal Power | 200W |
Peak Power | 800W Peak |
Dispersion (H×V) | 140°×30° |
Crossover Point | Built-in crossover 2KHz |
System Type | Passive 2-way coaxial line array |
HF drivers | 1×1.5" HF driver (38-turn voice coil tweeter) |
MF drivers | 1×6.5" MF driver (38mm voice coil) |
Paint | Scratch-resistant black speckled paint |
Dimensions (H×W×D) | 230×270×230 (mm) |
Net Weight | 5.5kg |
Dual 15-Inch Subwoofer | |
Frequency Response | 30Hz-200Hz (±3dB) |
Sensitivity | 95dB/W (lm) |
MAX. SPL. | 125dB MAX. |
Nominal Impedance | 8Ω |
Nominal Power | 1200W |
Peak Power | 4800W |
Amplifier Power | 1200W+800W+800W (3 channels) |
LF Drivers | 2×15" LF drivers (75-turn voice coil subwoofer) |
Dimensions (H×W×D) | 100×44.5×45.5 (mm) |
Net Weight | 44kg |
